Medicine Machine: Medicine Machine: Capsule relatived pharmaceutical...

Medicine Machine: Medicine Machine: Capsule relatived pharmaceutical...: Medicine Machine: Capsule relatived pharmaceutical machine : ...

Sunday, 23 February 2014

Medicine Machine: shenhu HT-201 Automatic Syrup filling machine

Medicine Machine: shenhu HT-201 Automatic Syrup filling machine: ...

shenhu HT-201 Automatic Syrup filling machine

Quick Details

Type: Filling Machine Condition: New Application: Food,Beverage,Commodity,Chemical
Packaging Type: Bottles Packaging Material: Wood Automatic Grade: Automatic
Driven Type: Pneumatic Voltage: 220V 50HZ Power: 0.96KW
Place of Origin: Shanghai China (Mainland) Brand Name: SH Model Number: HT-201
Dimension(L*W*H): 2560*1300*1600 mm Weight: 450kg Certification: CE
After-sales Service Provided:
Engineers available to service machinery overseas



Specifications
shenhu HT-201Syrup filling machine:
1.GMP standard
2.no bottle no filling feature
shenhu HT-201 Syrup filling machine

 Main characteristic
The automatic liquid filling and capping machine can automatically finish the bottle into ,bottle filling, bottle capping,bottle outing. With the no bottle no filling feature.
The machine with scientific structure can be single used, and also can be used with  production line .It is the ideal liquid filling production equipment, completely meet with GMP requirements.
Technical parameters
Productivity40-60bottles per minute(65ml)
Filling volume10-20ml
Bottle Diameter10-30mm
Bottle height50-300mm
Voltage220V/50Hz
Power0.96kw
Accuracy1%
Capping rate≥98%
Weight450kg
Dimension2560*1300*1600 mm
Machine part picture

Cap unscrambler
Cap unscrambler
Filling nozzle

Saturday, 22 February 2014

Medicine Machine: Capsule relatived pharmaceutical machine

Medicine Machine: Capsule relatived pharmaceutical machine: ...

Capsule relatived pharmaceutical machine

Quick Details

Control Mode: Full Automatic Place of Origin:       Zhejiang   China (Mainland) Brand Name: UNIWONDER
Model Number:     UW NJP-200/400/800

Specifications
Capsule Filling Machine
Pharmaceutical, medicine, and chemicals,also can be used to fill vitamin, foodstuff and animal drug etc
Capsule Filling Machine

Application:
Pharmaceutical, medicine, and chemicals (powder, Pellet, granule, pill), also can be used to fill vitamin, foodstuff and animal drug, etc.
Features
.Touching-screen, PLC program control panel with LCD.
.Capsule vacuum positioned mechanism to make the capsule qualified over 99%.

. Removable powder hopper for cleaning and easy auger adjustment easy to change fills weights.

. Easy speed selection and closed capsule length adjustment.

. Electrical Appliance control system approved to CE, and international standard.

.Quick and accurate change part set-up, easy to remove rotary table
 and ring carrier assembly.

.Fully enclosed rotating table and dosage stations for integration of the whole capsule filling plants.

.Large cam mechanism keeps the rotating table of mould together with the whole equipment running in balance, and completely guarantees the machine operating with highest precision and accuracy.

New Design of Fully Enclosed Rotating Table

capsule relatived pharmaceutical machine

. With high efficiency, accuracy, and energy saving.

. Easier to clean, dismantle and re set-up the mould.

. The working station cam runs under the good lubricating condition, extends the operating life of change parts.

. Improved the inner design of Mould rotating table, Import 90 pcs beeline bearings for each machine from Japan directly, guaranteed the equipment precision and extended the life of machine.

 New Design of Fully Enclosed Dosage Station

capsule relatived pharmaceutical machine

. Easier to clean; keep the dosage in accuracy.

. Enlarge the size of dosage pan (Enlarge 3cm); Increase the powder flowing uniformity in the dosage pan, according to the international standard.

. Adopt three dimensional control elements; Take the undersurface plane of dosage as datum, so as to eliminate the natural transmutation of the dosage pan and copper saucer. It is the special design at domestic (Patent No. 20042006795X).


Technical Details:
Model No.
UW-NJP-200
UW-NJP -400
UW-NJP -800
Capacity
200 capsules/min
400 capsules/min
800 capsules/min
No. of Dose
2
3
6
Suitable for Capsule
00#-4#
00#-4#
00#-4#
Total Power
3kw
3kw
4kw
Overall Weight
700Kg
700Kg
800Kg
Machine Dimension
580 x 900 x 1700mm
730 x 950 x 1700mm
820 x 960 x 1800mm
Accuracy
+ 1% Depending upon the consistency, uniformity & bulk density of powder under the controlled level of humidity.


capsule relatived pharmaceutical machine

capsule relatived pharmaceutical machinecapsule relatived pharmaceutical machine
capsule relatived pharmaceutical machine
capsule relatived pharmaceutical machine

capsule relatived pharmaceutical machine

Friday, 21 February 2014

Thursday, 20 February 2014

Medicine Machine: high speed mixing granulator model FL

Medicine Machine: high speed mixing granulator model FL:              Quick Details Machine Type: Granulator ...

high speed mixing granulator model FL












 Quick Details
  • Machine Type: Granulator
  • Condition: New
  • Product Type: granulator
  • Place of Origin: China (Mainland)
  • Brand Name: KY
  • Model Number: FL-120
  • Certification: ISO
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Packaging: standard export packaging
  • port: shanghai
  • price: get best price
  • brand: KY





Specifications
 The fluid bed granulator is a high efficiency fluid bed granulator
The fluid bed granulator is widely used


                                              FL Series Fluidized Bed Granulating Machine
PrincipleThe powder granule the container (fluidization bed) appears the state of fluidization. It is preheated and mixed with clean and heated air. At the same time the solution of adhesive solvent is fogged and sprayed into the container. It makes the some particles become granulating that contains adhesive. Being of unceasing dry through hot air, the moisture in the granulating is evaporated and the adhesive is solidification. The process is carried out continuously. Finally it forms ideal, uniform and porous granules.

ApplicationsPharmaceutical industry: tablet, capsule, low sugar or no sugar granule of Chinese medicine.
Foodstuff: cocoa, coffee, milk powder, juice of granulate, flavoring and so on.
Other industries: peticide, feed chemical fertilizer, pigment, dyestuff and so on.
Pharmaceutical industry: tablet
FeaturesBecause of powder Granulating, the flow property is improved and the dust is reduced;
Because of powder Granulating, its solving property is improved;
The mixing, Granulating and drying can be completed in one step inside the machine;
The operation of equipment is safe because the anti static filtering cloth is adopted;
The operation personnel can not be damaged if explosion take place because there is releasing hole;
The equipment has no dead corner. Therefore the loading and unloading are quick and light and clean. It can meet the requirements of GMP

Technical Parameter

itemunit type
35153060120200300500
containervolumeL12224510022042067010001500
diametermm30040055070010001200140016001800
capacity minkg1.5410153080100150250
maxkg4.56204590160300450750
fanair volumem3/h100012001400180030004500600070008000
pressuremmH2O375375480480950950950950950
powerkw345.57.51118.5223045
steam consumption kg/h15234270141211282366451
compressed air expenditurem3/min0.90.90.90.91.01.01.11.51.5
weight of the main bodykg500700900100011001300150018002000
steam pressureMpa0.3-0.6
temperatureCadjustable at the range of room temperature to 120°C
working timemin45-90 (decided in accordance with the properties of raw materials)
collect rate%≥99
noisedB(A)≤75dB(A) (When installation, main machine is separated from fan.)
overall dimensionsm1.0
*0.6
*2.1
1.2
*0.7
*2.1
1.25
*0.9
*2.5
1.6*
1.1*
2.5
1.85*
1.4
*3
2.2
*1.65
*3.3
2.34
*1.7
*3.8
2.8
*2.0
*40
3
*2.25
*4.4


Wednesday, 19 February 2014

Medicine Machine: SFG-B full automatic medicine box making machine

Medicine Machine: SFG-B full automatic medicine box making machine:   Quick Details Product Type: ...

SFG-B full automatic medicine box making machine



Quick Details


Product Type: Folder Gluer Processing Type: Folder Gluer Place of Origin: Zhejiang China (Mainland)
Model Number: SFG-B


Specifications

medicine box making machine
SFG-B high speed automatic paste box machine possesses the SHH-800 all functions,

medicine box making machine
SFG-B high speed automatic paste box machine possesses the SHH-800 all functions, Use of imported electrical appliances, and accessories for export with a rubber roller Paper can be pressed together by the processes as well as possesses the features of beautiful modeling, high speed and can made more wide boxes etc.Which can paste and manufacture from Widely uses in paste process for medicine box, wine box, cosmetics box and electric equipment package etc., It’s essential equipment in packing printing industry.

Major technical index
SFG-800B
Type of boxex
(Amax)
(Amin)
(Bmax)
(Bmin)
(Cmin)
(Dmin)
(Fmin)
box
700mm
70mm
620mm
110mm
8mm
70mm
51mm
SFG-1200B
Type of boxex
(Amax)
(Amin)
(Bmax)
(Bmin)
(Cmin)
(Dmin)
(Fmin)
box
700mm
70mm
800mm
110mm
8mm
70mm
51mm

SFG-B full automatic medicine box making machineSFG-B full automatic medicine box making machine

Monday, 17 February 2014

Sunday, 16 February 2014

Medicine Machine: YXT-YGD medicine aseptic filling machine

Medicine Machine: YXT-YGD medicine aseptic filling machine:                                                                                       Qu...

YXT-YGD medicine aseptic filling machine
















Quick Details

  • Type: Capping Machine
  • Condition: New
  • Application: Chemical
  • Driven Type: Electric
  • Automatic Grade: Automatic
  • Power: 2.2KW
  • Packaging Type: Bottles
  • Packaging Material: Wood
  • Place of Origin: Shanghai, China (Mainland)
  • Brand Name: kuixing
  • Model Number: YXT-YGD
  • COLOR: silvery
  • material: SUS304/316
  • certificate: ISO9001:2008
  • Type: Filling Machine





Specifications

1.aseptic filling machine
2.capacity:1500-1800bph
3.filling range:20-500ml
4.dimension:3000*900*1500mm

♦YXT-YGD medicine aseptic filling machine♦

Technical parameter:



applied bottle range20~500ml
quantity error±1%
auto adding stopper ratio≥99%
power supply380V 50Hz
Power consumed2.2KW
vacuum degree equipped6.6×10-2Mpa
vacuum consumed quantity equipped14m3/h
overall dimension3000×900×1500(mm)
weight750kg
production capacity:(four-head filling)20ml-100ml    3000~3600 bottles/h
100ml-250ml   2500~3000 bottles/h
250ml-500ml   1500~2500 bottles/h

Functions:

n         Computer control filling quantity, wriggle pump fills high precision, large range of adjusting dosage, it is applicable for various viscosity.
n         Filling syringe needle won’t touch with medicine each other, no pollution.
n         Wriggle pump filling system is convenient to clean, sterilize.
n         Not to fill without bottle, automatic stop as no bottle, bottle collapsed.
n         Auto display and count.
n         Filling system has the function of shrinking, no drop leak.
n         Equipped with Omron frequency conversion mechanism.
n         Frequency conversion adjusting speed.
n         The whole machine is designed according to the requirements of GMP.








n         The whole machine is designed according to the requirements of GMP.
