Vacuum emulsifying machine

Vacuum emulsifying machine

Quick Details
Place of Origin: Zhejiang China (Mainland) Brand Name: Meizhihe Application: cream,ointment, shampoo, lotion
Type: Emulsifying Machine working capacity(liter): 5-5000 min production(liter): 500
jacket pressure(Mpa): 0.3 mirror polish grade: 350MESH high speed homogenizing(rpm): 0-3500
jacket material: SUS304 material contacting parts: SUS316L
Specifications
1. GMP standard
2. CE certificate
3.Effective capacity:1000L
4.Meterail contacting parts SS316L
KRZRJ-1000  vacuum emulsifying mixer

1.Total volume: 1300L
Working volume: 1000L
Minimum production: 500L
Jacket pressure: 0.3MPa
Structure: Top standard oval-shaped sealing head is connected with flange.
Bottom standard oval shape sealing head is connected with body of tank,  with
jacket and thermal insulation layer.

2 .All parts contacting with material adopts SUS316L stainless steel. The internal layer is mirror polished up to 350 MESH grade, Ra≤0.4μm, thickness of the material: 8mm.

3 .The  jacket adopts SUS 304 stainless steel,  thickness of material: 6mm.
Between the internal layer and jacket, there is diversion channel for heating or
cooling by steam or cooling water.

4 .The thermal insulation layer adopts rock wool or PU. When jacket is heated by steam, the temperature of the external body of tank is less than 40°C. The external layer of the tank body adopts SUS304 stainless steel.  The external surface of tank is polished up to Ra≤0.4μm. Thickness of the material: 2mm. All the welding seams adopts flanging arc transition after polish.

5 .Top sealing head attatched: liquid inlet Φ38mm FDA standard (equiped with sanitary grade  butterfly valve and  stailness steel pipe filter), vacuum hole Φ25mm, compressed air inlet Φ20mm, vacuum breaking hole Φ38mm( equiped with 0.22μm dust-proof aspetic breather),sight glass with light DN100mm (the glass adopts stalinite with thickness of 10mm), two CIP cleaning balls Φ25mm ,particle
inletΦ38mm(with cover) ,sanitary grade diaphragm style pressure guage and pressure sensor switch.

6 .Bottom attached: material outlet Φ50mm ( equiped with sanitary grade pneumatic
bottom valve),PT100 temperature senor(0-150°C).

7 .High shear vortex emulsifying mixer: 15KW, 0-3500r/min ( variable frequency control).

8 .Slow speed wall scraping stirring:
frame style wall scraping stirring (clockwise): 4KW, 0-45r/min, variable frequency control.  The material of scraper is made of asepsis PTEF . The scraper can be easily removed by people without  tools.  Middle stirrer (anti-clockwise) and  scraper adopt the same reducer.
